Solis Download datasheet (PDF)
Solis S6-EH3P125K-H Solarator 125kW Three Phase HV Hybrid Inverter IP66
Rs 2,670,000
Price updated: 25 Oct 2026
In Stock
QuantityOnly 3 left
Delivery in 2-5 working days · Free delivery
The Solis S6-EH3P125K-H is a 125kW three phase high voltage hybrid inverter from the Ginlong Solarator series — the most powerful model in the Solis Pakistan commercial HV range. With 250kW of PV input across 10 MPPTs, 200A HV battery charging, multi-unit parallel up to 1.25MW, dynamic reactive power compensation and comprehensive peak shaving, it is designed for large industrial and C&I applications in Pakistan.
Key Features:
- 125kW rated output | Three phase | 380V/400V
- 250kW recommended PV array
- 10 MPPTs | 20 string inputs | 150-950V MPPT range
- HV battery: 300-950V | 200A max charging
- Two independent battery ports
- 160% overload for 200ms in off-grid mode
- Less than 10ms backup switching
- Multi-unit parallel up to 1.25MW
- Peak shaving and demand management
- Dynamic reactive power compensation
- DC and AC coupling support
- IP66 weatherproof
- SolisCloud AI monitoring
- 97.7% maximum efficiency
| Power | 125 kW |
|---|---|
| Phase | Three Phase |
| Type | HV Hybrid Inverter (C&I Solarator) |
| Battery Voltage | HV 300-950V |
| MPPT | 10 |
| Backup Switch | <10ms |
| Battery Ports | 2 (Independent) |
| Efficiency | 97.7% |
| IP Rating | IP66 |
| Max Charge Current | 200A |
| Max Input Strings | 20 |
| Max PV Array | 250 kW |
| Max PV Voltage | 1000V |
| Model | S6-EH3P125K-H |
| MPPT Range | 150-950V |
| Overload | 160% (200ms off-grid) |
| Parallel | Up to 1.25MW |
| Peak Shaving | Yes |
| Reactive Power | Dynamic compensation |
1 Year Manufacturer Warranty. Contact us on WhatsApp for warranty claims.
Customer Reviews
–
0 reviews
- 5 star0
- 4 star0
- 3 star0
- 2 star0
- 1 star0
No reviews yet — be the first to share your experience.
Frequently Asked Questions
- The Solis S6-EH3P125K-H 125kW is designed for large industrial and commercial facilities in Pakistan including large textile mills and garment factories with 80-120kW of three phase machinery, large hospitals with 100+ kW of critical medical, HVAC and support loads, large hotels above 300 rooms with centralised cooling systems, large shopping malls and commercial complexes with heavy refrigeration and HVAC, large university campuses with multi-building backup requirements and medium-scale industrial parks needing partial facility backup. With 250kWp of solar and 125kW output, this system can generate 1000-1250kWh per day in Pakistani conditions.
- The Solis S6-EH3P125K-H 125kW at Rs 2,670,000, Sigenergy Sigen 125kW at Rs 2,550,000 and GoodWe GW100K at Rs 2,100,000. Power: Solis and Sigenergy at 125kW lead GoodWe at 100kW. Battery: Solis HV 300-950V, Sigenergy HV, GoodWe HV — all similar. MPPTs: Solis leads at 10 MPPTs versus Sigenergy at 8 and GoodWe at 8. Parallel: Solis at 1.25MW, Sigenergy similar, GoodWe at 1MW. Reactive power: Solis has dynamic compensation, Sigenergy has it, GoodWe does not. Peak shaving generator mode: Solis only. Price: Solis at Rs 2,670,000 is Rs 120,000 more than Sigenergy and Rs 570,000 more than GoodWe 100kW. For 125kW capacity with generator peak shaving, Solis is the premium choice.
- For a large Pakistani textile factory consuming 150,000 kWh per month at Rs 55 per unit (Rs 8,250,000 per month), a Solis 125kW system with 250kWp solar generating 37,500 kWh per month saves Rs 2,062,500 per month in consumption charges. Adding demand charge savings from peak shaving (Rs 300,000-500,000 per month) and reactive power compensation (Rs 200,000-300,000 per month), total monthly savings reach Rs 2,562,500-2,862,500. Full system investment (inverter Rs 2,670,000 + batteries Rs 5,000,000 + 500 x 500W panels Rs 25,000,000 + installation Rs 2,500,000) = approximately Rs 35,170,000. Simple payback: 12-14 months. A compelling industrial investment.
- The Solis S6-EH3P125K-H supports AC coupling, allowing it to integrate with existing large grid-tie solar systems without replacing them. For a Pakistani factory that already has a 100kWp grid-tie solar system and wants to add battery backup and island mode capability, the Solis 125kW can be AC-coupled to the existing installation — avoiding the cost of replacing a functional grid-tie inverter. AC coupling also allows integration with existing wind turbines and captive power plants in hybrid microgrid configurations. The three-in-one interface on the Solis 125kW supports simultaneous on-grid PV, wind power and diesel generator connections for maximum energy source flexibility.
- SolisCloud provides comprehensive monitoring for the Solis 125kW industrial installation including real-time generation data (PV output, battery SOC, grid import/export, load consumption), historical analysis (daily, monthly, yearly energy reports), alarm and fault management (instant notifications for faults, grid anomalies and battery issues), remote control (charge/discharge scheduling, peak shaving setpoints, generator control), power quality monitoring (power factor, reactive power, harmonics) and multi-inverter dashboard for parallel installations. For industrial users in Pakistan, SolisCloud demand management module helps optimise against NEPRA industrial tariff structures to minimise peak demand charges and maximise net metering credits.
