SAJ H2 10kW Hybrid Inverter 1 Phase LV IP65
Price updated: 04 Oct 2026
In Stock
Delivery in 2-5 working days · Free delivery
The SAJ H2 10kW Single Phase Low Voltage Hybrid Inverter is ideal for larger homes and small commercial properties in Pakistan. With 240A fast charge/discharge current and support for up to 4 units in parallel, it provides scalable, intelligent solar backup for heavy loads including multiple ACs and commercial equipment.
- Max. 20A PV input current with 200% DC oversizing
- 240A fast charge/discharge current
- Compatible with LFP and Lead-Acid batteries
- Up to 4 units parallel — on-grid and off-grid
- Intelligent energy management with generator and heat pump
- 63A bypass current for whole home backup
- Wi-Fi / Ethernet / 4G monitoring
See how it compares in our Best Solar Inverter in Pakistan 2026 guide.
| Power | 10 kW |
|---|---|
| Phase | Single Phase |
| Type | LV Hybrid Inverter |
| Battery Voltage | Low Voltage (40–60V) |
| MPPT | 2 |
| Warranty | 5 Years (extendable to 10) |
| Battery Type | LFP / Lead-Acid |
| Communication | Wi-Fi / Ethernet / 4G (Optional) |
| Dimensions | 590×380×241 mm |
| Max Charging Current | 240A |
| Max DC Voltage | 500V |
| Max Efficiency | 97.6% |
| Max PV Input | 20000 Wp |
| Weight | 29 kg |
5 Years (extendable to 10) manufacturer warranty. Contact us on WhatsApp for warranty claims.
Customer Reviews
–
0 reviews
- 5 star0
- 4 star0
- 3 star0
- 2 star0
- 1 star0
No reviews yet — be the first to share your experience.
Frequently Asked Questions
- Yes, the SAJ H2 10kW can run two 1 ton ACs simultaneously along with other household appliances, provided the total combined load stays within 10000W. For a typical Pakistani household running two 1 ton ACs (approximately 3000W combined), refrigerator, water pump, fans and lights, the total load is usually around 5000-6000W, well within the 10kW capacity. If you plan to run two 1.5 ton ACs, we recommend considering the 12kW single phase or the three phase models for comfortable headroom above your peak load.
- The SAJ H2 10kW accepts up to 20000 Wp of solar panel input across 2 independent MPPT trackers, with 200% DC oversizing capability. This means you can connect panels rated up to 20kWp even though the inverter outputs 10kW of AC power. In Pakistan's solar irradiance conditions, this oversizing strategy maximises energy harvest during early morning, late evening and overcast days when panels produce below their rated output. A typical installation would use 30 to 36 panels of 550W each to fully utilise the 10kW capacity.
- Yes, the SAJ H2 10kW is an excellent choice for small offices, shops, clinics and commercial setups in Pakistan with moderate electrical loads. Its 10000W continuous output can handle commercial air conditioning, computers, servers, lighting, CCTV systems and other equipment simultaneously. The support for up to 4 units in parallel means you can scale to 40kW total output as your business grows. The 63A bypass current ensures whole building backup during grid outages, which is critical for businesses that cannot afford downtime during Pakistan's frequent load shedding.
- The SAJ H2 10kW is rated for operation from -40°C to +60°C, with intelligent derating above 50°C to protect the inverter. In Pakistan's summer months when temperatures in cities like Karachi, Multan and Lahore regularly exceed 45°C, the inverter's intelligent fan cooling system activates to maintain optimal operating temperature. The IP65 protection rating ensures dust and moisture resistance for outdoor or semi-outdoor installation. Performance may slightly derate during extreme heat, which is why proper ventilation and shade for the inverter mounting location is always recommended in Pakistan.
- The SAJ H2 10kW comes with a 5 year standard manufacturer warranty that can be extended to 10 years through SAJ's official extended warranty program. With over 8000 staff globally and products installed in more than 100 countries, SAJ Electric stands behind its products with robust after-sales support. In Pakistan, SAJ inverters are backed by an authorised distribution and service network. The 5 to 10 year warranty reflects SAJ's confidence in the inverter's reliability and is one of the strongest warranty offerings in the Pakistani solar inverter market.
- The SAJ H2 10kW is a single phase inverter designed for residential properties and buildings with single phase electricity connections, which is the most common type in Pakistani homes. The SAJ H2 12kW three phase is designed for buildings with three phase grid connections, typically commercial properties, factories and larger buildings. Three phase systems distribute load more evenly across three electrical phases, reducing voltage imbalance. If your property has a single phase meter, choose the 10kW. If it has a three phase industrial connection, the three phase models are more appropriate.
