GoodWe Lynx A 5kWh LV LiFePO4 Rack Battery IP21 (LX A5.0-10)
Rs 275,000
Price updated: 25 Oct 2026
In Stock
Quantity
Delivery in 2-5 working days · Free delivery
Key specifications
- Type
- LV Lithium Rack Battery
- Communication
- CAN
- Dimensions
- 442×133×420 mm
The GoodWe Lynx A 5kWh LV is a compact low voltage LiFePO4 rack battery from GoodWe, designed for residential solar systems with GoodWe low voltage inverters. With 100% depth of discharge, Cell-to-Pack (CTP) battery design for high energy density and flexible cabinet/floor/wall mounting, it is an excellent modular battery choice for Pakistani homes looking to start small and expand storage incrementally.
Key Features:
- 5kWh usable capacity at 100% DOD
- 51.2V nominal | LiFePO4 chemistry
- 60A nominal charge/discharge current
- 3kW nominal power
- Up to 15 units in parallel (75kWh)
- Cell-to-Pack (CTP) design for high energy density
- Cabinet, floor-stacked and wall-mounted installation
- Remote diagnosis and auto reboot via inverter
- Compact and lightweight at 40kg
- CAN communication
- IP21 indoor rated
- Compatible with GoodWe residential storage inverters
| Type | LV Lithium Rack Battery |
|---|---|
| Communication | CAN |
| Dimensions | 442×133×420 mm |
| DOD | 100% |
| Installation | Cabinet / Floor / Wall |
| IP Rating | IP21 |
| Model | LX A5.0-10 |
| Nominal Charge Current | 60A |
| Nominal Discharge Current | 60A |
| Nominal Power | 3 kW |
| Nominal Voltage | 51.2V |
| Scalability | Up to 15 units parallel |
| Series | Lynx A |
| Usable Capacity | 5 kWh |
| Voltage Range | 47.5-57.6V |
| Weight | 40 kg |
1 Year Manufacturer Warranty. Contact us on WhatsApp for warranty claims.
Customer Reviews
–
0 reviews
- 5 star0
- 4 star0
- 3 star0
- 2 star0
- 1 star0
No reviews yet — be the first to share your experience.
Frequently Asked Questions
- The GoodWe Lynx A 5kWh LV uses CAN communication and is designed specifically for GoodWe residential storage inverters including the ES Uniq 6-12kW and ET LV 12-20kW series. For GoodWe inverter owners, the Lynx A 5kWh provides seamless plug-and-play integration with automatic BMS communication and SEMS portal monitoring. Compatibility with other brands depends on their CAN protocol implementation. For buyers with non-GoodWe inverters, the Pylontech Fidus 5.12kWh at Rs 255,000 or BYD Battery-Box LV5.0+ at Rs 268,500 are better alternatives with broader inverter compatibility. Contact MartOnline on WhatsApp (+92 324 3493060) to confirm compatibility with your specific inverter before purchase.
- Up to 15 units of the GoodWe Lynx A 5kWh can be connected in parallel, scaling total storage from 5kWh (1 unit) to 75kWh (15 units). For a typical Pakistani home with a GoodWe ES Uniq 8kW inverter experiencing 8 hours of daily load shedding, 3 units (15kWh) provide comprehensive backup including 1 ton AC operation. The modular approach allows starting with 1-2 units and adding more as budget allows — each additional unit adds 5kWh of storage. Multiple units connect using a battery combiner box for safe parallel operation.
- The GoodWe Lynx A 5kWh at Rs 275,000, Luminey Atrix 5kWh at Rs 230,000 and Pylontech Fidus 5.12kWh at Rs 255,000 are all 5kWh LV rack batteries. Capacity: GoodWe at 5kWh matches Pylontech at 5.12kWh and Luminey at 5kWh. Charge/discharge: Pylontech leads at 100A versus GoodWe at 60A and Luminey at 80A. IP rating: Pylontech at IP65 leads GoodWe at IP21 — GoodWe is indoor only. Parallel: Luminey at 24 units leads GoodWe at 15 and Pylontech at 20. Inverter compatibility: GoodWe Lynx A is limited to GoodWe inverters versus universal compatibility for Pylontech and Luminey. Price: GoodWe at Rs 275,000 is the most expensive. For GoodWe inverter owners the Lynx A is the optimal choice for ecosystem integration; for non-GoodWe buyers, Pylontech or Luminey offer better value.
- Cell-to-Pack (CTP) is an advanced battery manufacturing technology used in the GoodWe Lynx A 5kWh where battery cells are assembled directly into the pack without intermediate modules — eliminating the module layer found in conventional battery designs. This results in higher energy density (more kWh in the same volume), fewer components (lower failure points), lower manufacturing cost and lighter weight. For Pakistani buyers, the practical benefit is a more compact battery (442×133×420mm, 40kg) that fits in tighter spaces while delivering the same 5kWh of storage as bulkier competing batteries. The CTP design also improves thermal management by allowing better heat dissipation directly from cells.
- The GoodWe Lynx A 5kWh comes with GoodWe manufacturer warranty — backed by GoodWe Technology Co., Ltd., a publicly listed Chinese company (SSE: 688390) with global solar inverter and battery deployments across 100+ countries. GoodWe Pakistan presence through authorised distributors ensures warranty support is available locally. The Lynx A features auto reboot after undervoltage and remote diagnosis via the connected GoodWe inverter — allowing Goodwe technicians to diagnose and often resolve issues remotely through the SEMS monitoring portal. Purchase from an authorised GoodWe dealer like MartOnline to ensure genuine warranty coverage. Contact us on WhatsApp (+92 324 3493060) for warranty registration and post-installation support.
